| Configurations |
| Scanner | Input Diameter | 10 mm |
| Tracking Error | 0.2 ms |
| Marking Speed | 5000 mm/s |
| Positioning Speed | 10000 mm/s |
| 1% Full Scale | 0.32 ms |
| 10% Full Scale | 1.2 ms |
| Repeatability | < 2 μrad |
| Gain Drift | < 150 ppm/K |
| Offset Drift | < 50 μrad/K |
| Drift Over 8h | < 0.2 mrad |
| Nonlinearity | < 1% |
| Scan Angle | ± 0.35 rad |
| Interface | XY2 – 100 |
| Wavelength | 10600 nm, 1064 nm, 532 nm, 355 nm |
| Basic | Power | ± 15 V DC, 3 A |
| Weight | 1800 g |
| Working Temp | 25 ± 10°C |
| Configurations |
| Scanner | Input Diameter | 10 mm |
| Tracking Error | 0.11 ms |
| Marking Speed | 10000 mm/s |
| Positioning Speed | 16000 mm/s |
| 1% Full Scale | 0.26 ms |
| 10% Full Scale | 0.62 ms |
| Repeatability | < 2 μrad |
| Gain Drift | < 100 ppm/K |
| Offset Drift | < 25 μrad/K |
| Drift Over 8h | < 0.15mrad |
| Nonlinearity | < 1% |
| Scan Angle | ± 0.35 rad |
| Interface | XY2 – 100 |
| Wavelength | 10600 nm, 1064 nm, 532 nm, 355 nm |
| Basic | Power | ± 15 V DC, 3 A |
| Weight | 1800 g |
| Working Temp | 25 ± 10 °C |
| Configurations |
| Scanner | Input Diameter | 10 mm |
| Tracking Error | 0.11 ms |
| Marking Speed | 8000 mm/s |
| Positioning Speed | 15000 mm/s |
| 1% Full Scale | 0.26 ms |
| 10% Full Scale | 0.62 ms |
| Repeatability | < 2 μrad |
| Gain Drift | < 100 ppm/K |
| Offset Drift | < 25 μrad/K |
| Drift Over 8h | < 0.1 mrad |
| Nonlinearity | < 0.4% |
| Scan Angle | ± 0.35 rad |
| Interface | XY2 – 100 |
| Wavelength | 10600 nm, 1064 nm, 532nm, 355 nm |
| Basic | Power | ± 15 V DC, 5 A |
| Weight | 2100 g |
| Working Temp | 25 ± 10°C |
The G3 Base Galvo Scanner is a versatile optical scanning module with excellent cost-effectiveness and good processing performance. It is widely used in industries such as laser material marking, laser cutting, laser welding, 3D printing, laser cleaning, and is suitable for standard laser processing applications. The G3 Std Galvo Scanner is a high-speed, stable, and highly accurate optical scanning module, widely used in applications such as laser material marking, laser cutting, laser welding, 3D printing, laser cleaning, flight cable conduit materials, rapid QR code scanning, and more. It is suitable for mid to high-end application scenarios. G3 Ult II Galvo Scanner is a high-precision, fast, and highly repeatable optical scanning module widely used in laser material marking processing, semiconductor processing, FPC cutting, semiconductor flexible material cutting, biomedical testing, and other fields；The G3 Ult II Galvo Scanner adopts multiple anti-interference measures, offering strong system immunity, high reliability, good linearity, high repeatability, and short response time. The system utilizes an integrated design with a small size, light weight, and excellent sealing,ensuring stability during prolonged operation.
